Product Name

High frequency blister packing machine
  • Efficiency
  • Accurate
  • Perfection
Machine description


High frequency blister sealing/packing machine

It's suitable for all kinds of blister packing such blister and blister, blister and paper packing.

Usage:

1.To seal blister of PVC, PET, PET-G, PET-GAG, A-PET...
2. Clear blister packaging
3. Plastic clam-shell packaging
4. Plastic Blister with plastic blister packages
5. Plastic blister with cardboard packages
6. Positive/negative blister forming and packaging
It is especially designed for HF welding is a perfect machine for production of blister packages,
But it is multipurpose machine, for it can be used for industry like PU leather cover for pad,, safety vests, reflective signs, inflatable toys, cosmetics, folding packing box, automotive, medical, rehabilitation, packaging, recreation, textile and clothing, reflective garments,.etc.
The HF blister packaging welder series have HF power outputs from 5KW to 35KW 30kW for multi-cavity production loads and specialized products.

Features:

1. Anti-flash system, to protect the tooling / mould; C-Frame welded steel structure with integrated HF generator
2. Equipped with special high precision rotary indexing gear controlled by frequency inverter.
3. Automated HF weld cycles with adjustable rotating speed
4. With the use of touch screen HMI and programmable PLC operator can easily input parameters set.
5. Heated Upper platen with thermostat, for helping HF sealing process
6. Close off HF welding function, the machine can be use as Standard Heat Welder
7. Universal usage for PVC, PET-G,A-PET,GAG, PU, PET, PLA films
8. European-model square high frequency vibration box, more reliable and stable in output
9. CE rated machine; factory verified by SGS and BV;
10. Customer's site installation, training & maintenance available
11. Online service by Email, Fax, Video Online- allowing remote live video servicing of basic setup and repairs through the use of face-to-face online video.
12. High frequency welding press pneumatically operated

Optional  Features:
1. Fully shielded HF weld area with side safety gate
2. Touch screen programmable HMI / PLC
3. Protective HF radiation shield standard
4. Auto-tuning system optional
5. Hydraulic pressure

Parameters

机型Model

RJ-HF5SD

RJ-HF8SD

RJ-HF10SD

RJ-HF15SD

高周出力HF Power

5KW

8KW

10KWW

15KW

振荡频率Frequency

27.12MHZ

电源电压Power Supply

50/60HZ AC380V 3P

输入功率Input Power

9KVA

15KVA

18KVA

25KVA

振荡管Oscillation Tube

7T85RB/E3185

7T69RB

E3069

8T85RB

防火花闸流管Anti-sparking Tube

电子防护系统

上下电极间距Gap of  Electrode

250mm

150mm

150mm

上压板尺寸Upper board

200×350

400×300

400×300

450×400

下定板尺寸Working plate

400×300

500×400

500×400

600×400

外形尺寸Machine Size

660×1350×1730

660×1350×1730

1000×1800×2000

1300×1975×2500

净重Weight

500KG

500KG

600KG

800KG

machine picture

sample display
