Mainly used for all kinds of plastic suitable for PVC, PET, double blister or single blister products packaging,welding and cutting;
Synthetic leather car inner decoration, visor, costumes, trademarks, strap, holster, CD bags, swim ring, raincoat, warm water bag, PVC inflatable pillow, air bed, air cushion, mobile pool, tent, canvas and other type of thick film or composite membrane fusion.
Main features:
1. Strong output,frequency generated by the 27.12 MHZ and 40.68 MHZ, in line with international industry standard, all kinds of special electronic circuit control device, can avoid improper operation, make working fast, and make the quality good.
2. High sensitive electronic spark protection device, when the spark occurs can be automatically cut off the circuit, machine damage is reduced, when the current is too high, automatic cut off to protect oscillation tubes and rectifier.
3. Using shuttle table work alternately, location is accurate, flexible and working plate size can be customized as required;
4. The latest generation of high frequency design, low electromagnetic radiation, protect the personal safety, with the manual/auto, test, temperature control, pressure control, high frequency current regulation and other functions, takes less space, easy installation and maintenance;
5. The key parts adopt imported parts, machine quality guaranteed.
6. PLC operating system, the welding parameters such as welding time can be set up by PLC, 7 inch touch screen interface, display various parameters and output, speed, parameter adjustment, production within the micro computer screen set for production, when production to achieve automatic warning, convenient for user counting.
7. High frequency welding firm, has beautiful appearance.
Main Features:
With precise anti-spark system to protection device;
With double sides skates, accurate position and flexible action;
Usage:
It is suitable for single and double sides plastic packings, printing and leather printing;
Parameters:
|
Model
|
RJ-HF4S
|
RJ-HF5S
|
RJ-HF8S
|
RJ-HF10S
|
RJ-HF15S
|
|
Power Output
|
4000W
|
5000W
|
8000W
|
10000W
|
15000W
|
|
Voltage
|
50/60HZ AC380V 3P
|
|
Power Input
|
7KVA
|
9KVA
|
15KVA
|
18KVA
|
25KVA
|
|
Rectifier
|
SILICON RECTIFIER
|
|
Oscillation Tube
|
7T84RB
|
7T85RB/E3185
|
7T69RB
|
E3069
|
8T85RB/E3130
|
|
Anti-Spark Thyratron Tube
|
NL5557
|
|
Pressure Way
|
Air Pressure
|
|
Gap of Electrodes
|
250mm
|
150mm
|
150mm
|
|
Dimension of Upper Board
|
200*350
|
200*350
|
400*600
|
600*800
|
700*900
|
|
Dimension of Lower Board
|
400*600
|
400*600
|
600*800
|
800*1000
|
800*1000
|
|
Overall Dimension
|
660*1350*1730
|
660*1350*1730
|
1000*1800*2500
|
1000*1800*2500
|
1000*1800*2500
|
|
Net Weight
|
400KG
|
400KG
|
500KG
|
700KG
|
900KG
|
